TM-8100 series ♦ Eco-type Single-phase Power Meter
Short Description
It's measures AC/DC signals with simultaneous display of voltage, current, power, power factor/frequency, and 2nd–50th harmonics. Features 0.5-class true RMS accuracy, high noise immunity, RS232 communication and harmonic analysis. Ideal for production line testing of lighting products, home appliances, motors, power supplies, and more.
TM-8100 series is testing AC and DC signals, simultaneous display in four windows are voltage, current, power, power factor/frequency and 2nd-50th harmonics. All measurements are true RMS values. TRMS auto-ranging accuracy: 0.5 class, High immunity to external noise. Standard RS232 communication interface and harmonic testing software. Suitable for production line testing: such as lighting products, home appliances, motors, power supplies, etc. |
Features
LED digital screen display: voltage, current, power, power factor/frequency, 2-50 times Harmonic (TM-8120), Electric energy (TM-8140).
Can be set current and power lower and upper alarm function.
All measurements are True RMS.
Automatic range.
Support data locking.
Strong anti-interference.
Support data locking, MODBUS protocol (TM-8140).
Not affected by external noise.
The ratio coefficient can be set and can be equipped with a transformer or current clamp.
