TT-2500 series Multi-channel Temperature Tester
| TT-2500 series is mulit-channels temperature tester included 16 models, this series adopts 7 inch touch screen and support input of J, K, T, E, S, N, B, R type thermocouple. It can collect multi-channel data simultaeouslt, with intuitive number reading, bar chart and curve graph diplay modes, allowing users to read various parameter in multiple ways. Data can also be recorded on a USB storangedevice. Meanwhile, tester has upper and lower limit alarm functionand communication transmission capabilities. With it's prefect function, superior performance and simple operation, it can fully meet the measurement needs of production. laboratories and R&D. |
Features
7-inch 24-bit true color LCD screen, 1024X600 resolution.
2U height, support up to 64 channels scanning, the industry's highest integration temperature scanning tester.
3 scanning speeds : slow, fast and ultra-fast (100ms).
Automatic detection of broken couples, intuitive numerical display, histogram and graph display.
Specify channel scan.
Cold junction compensation.
Standard 8G USB flash disk and USB Host interface, supporting USB flash disk storage and flash disk segmentation.
Built-in 8GB SD card.
With a file system, shutdown does not lose current instrument settings.
Standard 8G U disk and USB Host interface, support U disk storage.
Ad hoc temperature upper and lower limit alarms and color changes warning for over-run reading, It can set the upper and lower limit for each channel.
Suitable for standard half 2U cabinet, ultra short chassis.
Soft switching function.
Screen capture function, data recording and parameter saving function.
Each channel can independently set sorting boundaries and handler sorting results and can be expended to 64 channels.
Tester firmware program can be upgraded via USB Host.
The handler interface ins used to achieve online operation. It is the only temperature scanner with a fully insolated handler interface in the industry, saying goodbye to the embarrassment of not being able to directly connect a temperature tester to a PLC.
